The Tetra HF high feed rate milling cutter is a completely new addition to the milling cutter range of the French toolmaker Safety. It will be unveiled to the trade and public for the first time at this year's EMO.
Equipped with four-sided, positive inserts and high performance cutting materials, this marvel of productivity is highly suited for economical roughing operations and the pre-finishing of tool forms. Thanks to the highly efficient and exceptionally robust high-feed cutter geometry in some materials a maximum feed per tooth (fz) of 2mm is possible at cut depth up to 1mm. According to the manufacturer, tool and mould makers should be especially pleased with the Tetra HF as it comes into its own in profile and copy milling with high chip volume and high feed rates.
The insert grades 5020 and 1130, can be used on a wide variety of materials. Grade 5020 consists of a fine grained substrate with a wear-resistant and tough PVD coating (TiAlN-TiN), which prevents the formation of hairline cracks. Besides machining steel and stainless steel, the universal tool material easily chews its way through temperature-resistant alloys and titanium. If you have to deal with spheroidal graphite iron and cast iron, then opt for 1130, the temperature-resistant CVD coating (TiCN-Al2O3) is especially tough and prevents pitting.
Image1: Tetra HF
Caption: Loves roughing it! The new Tetra HF high-feed milling cutter from Safety. The cutter is available in three shaft versions (cylindrical, screw-on head, and Morse taper) and initially in the diameters 25 to 52 mm.
http://www.pr-x.de/...
Image2: WSP Tetra HF
Caption: High feed geometry of the highest calibre: The new Tetra HF is equipped with rectangular, positive inserts that offer a large cutting radius.
http://www.pr-x.de/...
Image3: The Safety stand at the trade fair
Caption: The new Tetra HF high feed milling cutter is only one of the many highlights to be found at the EMO-Stand A36 in Hall 6.
http://www.pr-x.de/...
Safety, Rodgau: Comprehensive tool solutions - competent, flexible and fast
Safety, established in France in 1932, is an international manufacturer of precision tools for the metal cutting industry. The traditional company that employs about 500 employees all over the globe counts many famous names from the fields of Automotive, Aerospace, Die & Mould and Energy among its customers. Based on its own quality tools, activities focus on technical support and comprehensive tool solutions in standard and specialized fields: Together with Safety's specialists, users can quickly and flexibly optimize their production processes, increase productivity and reduce costs. In Germany, Safety is present with a sales office in Rodgau. www.safety-cuttingtools.com
