Time-Gated Measurement in the SignalShark IQ Analyzer

What does Time-Gated Measurement in the SignalShark IQ Analyzer mean?

(PresseBox) (Pfullingen, )


Overview here:
The Time-Gated Measurement (TGM) functionality in the IQ Analyzer for SignalShark enables precise signal analysis within specific time slots, particularly useful for time-division multiplexing systems like TDD. By focusing on defined time slots, TGM isolates uplink and downlink signals transmitted on the same frequency, significantly enhancing clarity and detail.

The Key Features:
- Flexible Configuration: Define time slots using markers in the Magnitude View.
- Gate Settings: Adjust parameters such as Gate Start, Stop, Offset, and Period to match specific signals of interest.
- Various views for Visualization: Display gated data in IQ Spectrum and Spectrogram Views for comprehensive insights.
- Dynamic Resolution: Choose between high time or frequency resolution via customizable RBW settings.

The Applications:
- TDMA Systems (5G, DECT, TETRA, P25): Isolate uplink/downlink/channels in TDMA based communication protocols.
- Regulatory Monitoring: Identify and analyze non-compliant signals or illegal transmitters.
- Interference finding: Analyze interference signals in unused time slots.
TGM in the IQ Analyzer is essential for professionals requiring targeted and precise signal analysis in dynamic frequency environments. More about the Option IQ Analyzer --> https://www.narda-sts.com/...
