From end of the year RGB LEDs with 6 colours will be available to adapt to the specific alarming needs on site. Brilliant colours in green, red, yellow, orange, white and blue represent the status of an input. Moreover analog cards with comprehensive settings are available soon providing the actual value on all protocol types i.e. IEC 61850, 60870-5-104 or Modbus, else signaling the under or overrun of a threshold via the digital inputs. Additionally in between or out of range monitoring is provided.
As maximum 20 analog values can be processed in one device. The analog cards can be mixed with other cards such as relay cards. Voltage ranges between 0V and +/- 10V or currents between 0 (4) … 20mA can be applied individually to each input. The whole configuration is carried out through the integrated web server, on which as well the physical SI can be shown, e.g. 43,27°C.
Thus makes the USM not only a common annunciator anymore, it is more and more becoming an I/O data turntable.
