Avalue's 3.5-inch Micro Smart I/O Module Embedded SBC

ECM-945GSE+ with AUX-301/302/303/304/305 Modules

ECM-945GSE Plus from Avalue
(PresseBox) ( Quickborn, )
Avalue’s latest innovative ECM-945GSE+ (Plus) is a highly integrated and modularized Single Board Computer. The computer is powered by Intel ® Atom™ N270 processor, which consumes low power, is energy-efficient and compatible with Intel®945GSE /ICH7-M IO control chipsets. It is embedded with DDRII memory with maximum memory capacity of 1G, supports 36-bit LVDS LCD and CRT+LVDS dual-screen display output, and supports 2 Mini PCIe and SATA interfaces each. It also comes with a gigabit ultra-speed Ethernet and six sets of USB 2.0 connectivity interfaces.

This innovative micro module single-board computer is connected to the multi-function I/O board card module (upper board) via the Pin-out method. This design resolves the problem of hardware space inadequacy and manufacturing cost is significantly reduced. The high I/O scalability fulfils different customer demands and gives them a wide array of choices. These I/O module combinations support DC wide-voltage input, from +10V to +28V (provided by micro IO module). The ECM-945GSE+ measures 146mm x 101mm. The I/O module dimension are 101.6mm x 59.35mm.


Avalue ECM-945GSE Plus I/O Modules

AUX-301 High-definition Sound Effect I/O Module
AUX-302 POS/POI Application I/O Module
AUX-303 Information Security Application I/O Module
AUX-304 Automobile I/O Module
AUX-305 Mobile Device I/O Module


More info on: http://www.texim-europe.com/...
