IGBT Driver core is smaller than a matchbox but with 20A output stage

SKYPER 12

Nürnberg, (PresseBox) - The SKYPER12 drives safely IGBT modules up to 400A. With the footprint of 35 x 45 mm the driver allows very compact inverter designs with small IGBT modules like Mini Dual or SEMiX 5. Thanks to a complete ground layer, adjustable filter management and optimised transformers with low coupling capacitance, the driver core can work properly in very compact designs with a high level of electromagnetic compatibility.

The new ASIC chipset offers safe short circuit handling with soft switch off and fast mode detection. Thanks to the integration level, an MTBF rate of up to eight million hours at full load can be realised. With that feature set the SKYPER12 IGBT driver core offers the optimised platform for IGBT modules in the range from 80A - 300A. Reference circuits for SEMiX 5, MiniSKiiP Dual and SEMiX 3 Press-Fit support customers for efficient driver integration.

Website Promotion

SEMIKRON International GmbH

SEMIKRON is one of the world's leading manufacturers of power modules and systems primarily in the medium output range (approx. 2 kW up to 10 MW). Our products are at the heart of modern energy efficient motor drives and industrial automation systems. Further application areas include power supplies, renewable energies (wind and solar power) and utility vehicles. SEMIKRON's innovative power electronic products enable our customers to develop smaller, more energy efficient power electronic systems. These systems in turn reduce the global energy demand.

SEMIKRON is a family owned business founded in 1951, headquartered in Nuremberg, Germany. Today the company has a staff of more than 3,000 people in 25 subsidiaries world-wide. This international network with production sites in Germany, Brazil, China, France, India, Italy, Korea, Slovakia and the US ensures fast and comprehensive service for customers. By establishing the ONLINE SHOP in 2009, SEMIKRON increased its presence for customers. The SEMIKRON ONLINE SHOP offers 24-hour availability and world-wide access with multi-language sales and technical support.
