New online module for calculating rolling bearings for electric motors and generators

Schaeffler Expands its Rolling Bearing Calculation Service

(PresseBox) (Herzogenaurach/Schweinfurt, )
The BEARINX-online family has a new member: Schaeffler customers can now use the "Easy EMachine" module to calculate electric motors and generators based on their typical mechanical and electromagnetic field loads. This new module, which is available online and can be used free of charge, therefore offers a fast and easy way to design bearings. Initial registration is simple and the customer can begin calculation work immediately.

Electric motors and generators with horizontal, vertical, and freely-selected orientation can be calculated at http://bearinx-online-easy-emachine.schaeffler.com. It is possible to quickly and reliably browse through and compare a range of different bearing support variants. The weight of the shaft, laminated cores, and windings as well as the magnetic tension and other freely configurable loads are available for selection. This means that belt pulleys, gears, and imbalances can be modeled at various speeds and in different load cases.

The program guides the user through each step of the calculation process, and the data that have been entered are shown as visualizations for checking. Last but not least, the bearings (the core of the electric motor) can be calculated in a wide range of variations. The data of INA and FAG rolling bearings can easily be loaded from an integrated database. The saved files can be exchanged with Schaeffler's Engineering Service or a local Schaeffler Technology Center for final inspection. The objective is to offer the customer optimized and efficient support in his or her own product development at all times and, in doing so, shorten development times.

The BEARINX-online Easy family - a calculation service for everyone

BEARINX is a leading calculation program for designing rolling bearings and allows complete transmissions and linear systems to be modeled and calculated with all the relevant data regarding elasticity, contact rigidity, and environmental influences. Schaeffler offers special online versions that allow numerous target groups to utilize the outstanding potential of the software, which the company developed in-house. The BEARINX-online Easy family is characterized by its ease of use and is available to everybody. INA and FAG products can be quickly and reliably calculated based on simple catalog formulae. The following modules are currently available: Easy BallScrew for ball screw bearing supports, Easy Friction for calculating rolling bearing friction, Easy Linear for calculating monorail guidance systems, Easy Linearsystem for single and multi-axis systems, and Easy RopeSheave for designing rope sheave bearing supports.

Website Promotion

Website Promotion

Schaeffler Technologies AG & Co. KG

The Schaeffler Group is one of the world's leading integrated automotive and industrial suppliers. The company stands for the highest quality, outstanding technology, and strong innovative ability. The Schaeffler Group makes a decisive contribution to "mobility for tomorrow" with high-precision components and systems in engine, transmission, and chassis applications as well as rolling and plain bearing solutions for a large number of industrial applications. The company generated sales of approximately 12.1 billion euros in 2014. With more than 82,000 employees worldwide, Schaeffler is one of the world's largest technology companies in family ownership and, with approximately 170 locations in 50 countries, has a worldwide network of manufacturing locations, research and development facilities, and sales companies.

The Industrial division supplies components and systems for around 60 industrial sectors via its worldwide organization with market proximity and its application support service. The range includes miniature bearings only a few millimeters wide through to large-size bearings with an outside diameter of several meters.
