Cost-effective 15-inch (38 cm) Lite+ TFT display with a brightness of 1200 cd/m² and a contrast ratio of 700:1

Specified for an operating temperature range of -30°C to +80°C

(PresseBox) (Stutensee (Germany), )
Gleichmann Electronics now offers a high performance 15-inch TFT display, part name TX38D18VM2BAA, from KOE Europe's range of Lite+ display modules. The TX38D18VM2BAA is a cost-effective, transmissive mode display solution with XGA (1024 x 768 pixels) resolution.

The 15-inch display has a high brightness rating of 1200cd/m² and a contrast ratio of 700:1 ensuring clear, concise image reproduction even in high ambient light environments. The TX38D18VM2BAA is suitable for both demanding industrial applications and typical outdoor applications such as kiosks, digital signage and point-of-sale (POS) terminals. The white LED backlight provides a guaranteed 50,000 hours half brightness lifetime.

The TX38D18VM2BAA, which is specified for an extended operating temperature range of 30°C to +80°C, has mechanical outline dimensions of 326.5 mm x 253.5 mm x 11.5 mm and has a 20-pin single channel LVDS interface that supports a color palette of up to 16.7 million colors.

Detailed information about KOE's 15-inch TFT display, part name TX38D18VM2BAA, and samples can be requested by sending an email to display-koe@msc-ge.com.

Website Promotion

Website Promotion

MSC Technologies GmbH

Founded in 1979, Gleichmann & Co. Electronics GmbH, which is part of the same group of companies with MSC Vertriebs GmbH, is one of the leading pan-European distributors of electronic assemblies and components. With the early focus on a small number of support-intensive product areas such as displays, optoelectronics and customized rechargeable battery packs, Gleichmann & Co. Electronics was able to build up unique system know-how over a number of years in the sectors previously mentioned. This in-depth technical know-how, which is unusual for a distributor, enables Gleichmann & Co. Electronics as Display Solution Center to support customers on an individual basis according to needs at each stage of the customer's application development. This support ranges from the traditional product advice and extensive design-in support up to taking over the entire product development. For further information about the products and services of Gleichmann & Co. Electronics, please visit: www.msc-ge.com.
