IP-67 Managed Industrial Switch w/8 PoE Injectors - 8 10/100TX + 2 100FX M12Klingenberg, )
Equipped with DC 48V redundant input power, Lantech IPES-2208F-67 is able to feed each PoE port up to 15.4Watts with IEEE 802.3af PoE standard. It also supports relay contact to connect with alarm system, which can immediately notify of power failure and/or port down events. In case of events, Lantech IPES-2208F-67 will immediately send an email to predefined addresses and send trap to stations.
Lantech IPES-2208F-67 supports our Pro-Ring system including X-Ring, which is able to find an autorecoverypath within 10ms up to 250 Lantech Industrial Switches and Dual-Homing feature ensures two X-Ring groups with redundant back up when connected to a backbone switch. Pro-Ring also provides Couple Ring, which is to ensure network recovery protection between two X-Ring groups. Furthermore, it can set backup masters in X-Ring to ensure the most secure network.
IPES-2208F-67 is designed to meet with critical network environment with IP67 enclosure and M12 connectors for protection against immersion in water. It passed several tests under extensive Industrial EMI and Safety standards. Besides 1.2KVA Hi-Pot abnormal test, it also passed stability testing such as Free fall, Shock, and Vibration. For more usage flexibilities, IPES-2208F-67 supports wide operating temperature from -40°C to 75°C.
Lantech IPES-2208F-67 is the best to be used in any critical industrial environment where needs PoE functionality.
