JTAG Test Routines Bend the Coverage Curve

Harnessing device functionality to test clusters

Eindhoven, the Netherlands, (PresseBox) - Test engineers have a new weapon in the battle to verify the operation of complex, non-boundary-scan clusters. In addition to its ActiveTest tool, JTAG Technologies now offers JTAG Functional Test (JFT) simplifying test preparation and interpretation of results for sequential clusters, testing mixed signal parts such as ADCs and DACs, testing parts that require user intervention, looping test patterns to set up device registers, etc.

JFT is the first product to emerge from boundary-scan technology that uses a recognized open-source programming language to give the test designer the ability to use JTAG devices to verify the functionality of non-JTAG devices or clusters. As a plug-in module to JTAG Technologies' pace-setting ProVision tool, JFT builds on the boundary-scan resources (BSDL files and models) adding a powerful command and control environment to manipulate and sense cluster I/Os. Within JFT, scripts are quickly prepared by means of a built-in Python script editor and a code template to perform the tests and collect the results. The available functions for any cluster device with the associated Python test model are directly visible in the editor. Other time-saving features are automatic completion lists and display of available function parameters within the tooltip.

JFT uses the Python programming language, a general-purpose high-level programming language that supports object-orientated programming. Using Python module programming in combination with ProVision's connection database also means that device test code can be written solely from the functional cluster perspective. The "bind model" feature encourages re-use of cluster tests by automatically mapping device-under-test pins to active boundary-scan pins.

JFT is available immediately with the most recent release of JTAG ProVision (CD15).

JTAG Technologies BV

JTAG Technologies is a market leader and technology innovator of boundary-scan software and hardware products and services, focusing on the development of boundary-scan technology. It was the first to bring to the market such important advances as automated test generation, automated flash and PLD programming via boundary-scan, and visualized boundary-scan analysis. Its customers include world leaders in electronics design and manufacturing such as Alcatel-Lucent, Ericsson, Flextronics, Honeywell, Medtronic, Motorola, Nokia, Philips, Raytheon, Rockwell-Collins, Samsung, and Sony. Its innovative boundary-scan products provide test development, test execution, coverage analysis and in-system programming applications.

With an installed base of over 6,000 systems worldwide, JTAG Technologies serves the communications, medical electronics, avionics, defense, automotive, and consumer industries with offices throughout North America, Europe and Asia. JTAG Technologies headquarters are located in Eindhoven, The Netherlands.

JTAG Technologies is a registered trademark of JTAG Technologies, Inc. All other brand names or product names mentioned are trademarks or registered trademarks of their respective holder(s).

www.jtag.com
