Following the successful launch last year of the highly acclaimed JTAGLive boundary-scan utility tools, JTAG Technologies has further bolstered the hardware interface support by introducing the JTAGLive USB Controller; a single TAP, IEEE Std. 1149.1 boundary-scan controller.
While JTAGLive already supports the use of the JTAG 'cables' from Xilinx and Altera, as well as JTAG Technologies' own established range of IEEE 1149.x controllers, increasingly JTAGLive users have been requesting a dedicated, low-cost, connection system that works 'out of the box' with the JTAGLive suite.
Peter van den Eijnden, MD of JTAG Technologies, commented: "While most users have been quite happy to use the built-in support options for Altera and Xilinx hardware, some users found it inconvenient to download and install the PLD support/driver software. By offering an affordable interface cable that customers can use with confidence, we believe boundary-scan usage will spread even further and faster."
The JTAGLive USB Controller is PC-powered and features a single test access port in JTAG Technologies' standard pin-out. It offers a maximum programmable TCK speed of 6MHz and also features programmable output voltages and input thresholds.
The controller has been designed for use exclusively with the JTAGLive suite of software tools that includes Buzz (a free-of-charge continuity tester), Clip (an interactive cluster test generator) and Script (a powerful Python-based boundary-scan scripting system).
The JTAGLive USB Controller costs just 195 Euro or 265 USD and is available for on-line ordering today by visiting www.jtaglive.com
