Epson Begins Volume Production of the SG2520 Series of Tiny, High-Frequency, Low Phase Jitter SPXOs
At 44% smaller than Epson's comparable previous products, the SG2520 series is ideal for small optical communications modules that support 400 G
Telecommunications network traffic and capacity continue to increase with the introduction of 5th-generation telecommunication systems (5G) and the evolution of mobile networks, the Internet of Things (IoT), Advanced Driver Assistance Systems (ADAS), and data centers. At the same time, the noise level permissible in communication signals is lower, and clocks used in network equipment must operate at high-frequency and have low phase jitter. Optical communication modules that connect network devices are becoming faster and smaller, and clocks with a frequency tolerance of ± 20 x 10-6 or less are needed for transmissions at ultra-high speeds of 400 Gbps and 800 Gbps and distances of 80 km or more.
Like Epson's earlier comparable products, the SG3225EEN and SG3225VEN, the new SPXOs offer frequencies up to 500 MHz and low phase jitter. In addition, they are equipped with a compact oscillator IC developed by Epson that compensates the temperature coefficient of frequency of the built-in HFF crystal oscillator4. The use of this IC enabled Epson to shrink the footprint of the SPXOs by 63% and their cubic volume by 44% compared to the previous products. Furthermore, they demonstrate superior frequency stability, with a frequency tolerance at -40 to +105˚C that is half that of the predecessor for SG2520EGN and SG2520VGN and 40% for SG2520EHN and SG2520VHN. The new series has the ideal characteristics for small optical communication modules. As a leader in quartz crystal devices, Epson will continue to provide crystal device products required in electronics and social infrastructure.
Product applications- Network equipment (routers, switches, optical modules, etc.)- Data centers- Factory automation equipment, measuring instruments- High-speed DA/AD converters Related links
Please see the link below for product details: https://www5.epsondevice.com/en/news/topics/sg2520xgn_xhn_lp.html
1 Differential output: A method that outputs frequency signals with opposite polarities. Differential output enables high-frequency transmission and has strong noise resistance.
2 Jitter: Fluctuations in the clock period that can cause things such as fluctuations in displayed images and bit errors in data transmissions.
3 Fundamental mode: The natural frequency at which a crystal unit vibrates.
4 High-frequency fundamental (HFF) crystal unit: A crystal unit that can oscillate at a high-frequency fundamental without compromising crystal chip strength because a photolithographic process is used to create an inverted-mesa structure in which only the vibrating area of the crystal chip is thinned to a thickness of several microns. HFF crystal units contribute to the stability of high-speed, high-capacity telecommunications because they can suppress nearby harmonic components.
