Changing the Program Instead of Changing the Tools

The Multiformat-Hybrid Bender of BEIL processes printing plates of all common printing machines

(PresseBox) (Abensberg, ) With its Multiformat-Hybrid Bender, BEIL Registersysteme GmbH presents a really innovative and cost-reducing highlight at this year’s drupa (May 29 to June 11, Messe Düsseldorf). On stand C74 in hall 9, the Bavarian enterprise presents a bender for printing plates, which can be adjusted to the bending angle of all common printing machines via intuitively operated software. The main advantage: One single bender processes printing plates for printing machines from different manufacturers.

The bending angle for the printing plates is defined by the manufacturer of the printing machines. The angle, the bender provides the printing plate with, was determined by its tools up to now. The logical consequence: If, for example, after the purchase of a new printing machine, a new bending angle was required, one had to buy an additional bender or retrofit the existing bender with high effort. This is not very efficient, does not save resources, and does not fit in BEIL’s strategy of sustainability. It is no wonder that the company from the asparagus region south of the old imperial town Regensburg did not rest until they found the solution for this problem:

At the Multiformat-Hybrid Bender, the bending angle is adjusted via program-controlled motors and can be changed within a large range via intuitively-operated software – even for double bendings. The operator must not have knowledge in programming – via a touch-screen, he simply selects the printing machine of which he wishes to bend the printing plates. Should the parameters of a printing machine not have been saved as a default in the device, BEIL Registersysteme GmbH can provide a software update.
The Multiformat-Hybrid Bender masters different bending radii through single, easily interchangeable elements. On top of that, printing plates of all kinds of different formats can be processed.

Thanks to its rollers, this device is mobile and its height-adjustable machine supports enable to position it so-to-speak stationary on basically any ground. A camera system and a 17 inch TFT screen support the operator during the precise adjustment of the printing plates. During bending, vacuum fixes the printing plate on the table of the Multiformat-Hybrid Bender. The electrical system can be operated both with 110 V AC, 60 Hz as well as with 230 V AC, 50 Hz. To be able to operate the vacuum system, the device requires a connection to a 6 bar standard compressed air network.

The low-maintenance Multiformat-Hybrid Bender is structured with the well-known BEIL quality and bears the CE stamp. A sensor-monitored safe guard and a sophisticated control system ensure safe work even at fast-paced times. A transparent, blue, toned protective cap protects the bender’s mechanical components.

For more information, please refer to .

BEIL Registersysteme GmbH

Since 1981, BEIL Registersysteme GmbH is the reliable system partner for leading printing machine manufacturers and quality-oriented printing companies when it comes to punching and bending of printing plates. Regardless if hand-operated or fully-automatic – the ISO-9001 certified company has optimal and affordable solutions for all requirements.

The headquarters of the company is located in the Lower Bavarian metropolis Abensberg, about 30 km south of the old imperial town Regensburg. Round 65 employees work on a 6,500 square metres production site with more than 70 state-of-the-art manufacturing machines and processing centres. Other round 30 staff members are employed in foreign subsidiaries.

The owner-operated company exports about 90% of its products to more than 185 countries.

To BEIL, sustainability is not just a matter of empty words. Not only does this company use material, energy and resources reliably, the earnings also remain in the company enabling further investments and securing the place of employment in the long run. It is BEIL’s defined goal to receive the ISO 14001 certification (environment management) by 2010.
