Product contaminations? No chance! AERZEN offers certified safety standards for the pneumatic industry

(PresseBox) (Aerzen, ) There are high demands on blower technology in pneumatic conveying of bulk material. This is not only caused by the fact that these systems have a key function in the material flow, but it is also based on the fact, that the quality of compressed air is of vital importance. In this context, Aerzener Maschinenfabrik GmbH has developed a new and certified safety standard, especially for the requirements in the pneumatic industry.

The purity of the compressed air and the final product both influence the quality of pneumatic processes. The production of high-quality products requires special attention to purity, safety and reliability. This claim applies to many industries: foodstuff, pharmaceutical and cosmetics industry, parts of the automobile industry, paper and textile industry as well as sensitive processes of the chemical and petrochemical industry.

First of all, the oil-free operation should be mentioned. Not only the contamination of bulk material with oil poses a potential hazard here, the contamination of the installed compressed-air system may be a risk factor as well. AERZEN, being among the world’s leading manufacturers of positive displacement blowers, rotary lobe compressors and screw compressors, has initiated an extensive certification according to ISO 8573 for all series together with TÜV Rheinland.  On that basis, an oil-free operation of class 0 had been confirmed and certified for AERZEN blower and compressor packages.

The AERZEN safety concept goes even further and therefore, the focus is also on the silencer technology. Discharge silencers which are lined with absorption material are still often used for blowers and compressors. However, this insulating material is subject to natural wear.  This wear is caused primarily by the high intake temperature of the air and the abrasive wear by the pulsations in the silencer. The absorption material is washed out of the silencer in fine particles and so it gets into the conveying air.

As a consequence of this, AERZEN has developed an entirely new silencer technology, which has been successfully patented. The sound level of these reactive silencers is reduced purely by means of air deflection.  The advantages: Process safety and compressed-air quality are guaranteed as well as a constant sound pressure level across the entire life cycle, as no wearing material is used. In addition, the silencers increase the energy efficiency by reduced pressure losses.

Often overlooked in pneumatic conveying systems is that blowers and compressors may produce sparks in case of malfunction and that, blown into the conveying pipe (pressure conveying), these sparks can ignite dust-air mixtures. The patented silencers made by AERZEN also play an additional key role, as thanks to the internal air deflection, the reactive silencers also serve as spark arresters. An innovative solution, inspected and certified by the TÜV. When using AERZEN blower and compressor packages, externally, on-site spark arresters are not needed anymore, offering a great advantage for plant manufacturers and plant operators as well. As besides the ATEX compliant safety, the AERZEN solution saves on investment costs and energy costs sustainably, as pressure losses caused by downstream spark arresters can be prevented.

Furthermore, AERZEN offers a solution portfolio for almost all ATEX zones which is unique for a wide range of applications and performances. The AERZEN packages Delta Blower, Delta Screw and Delta Hybrid are tailored specifically to meet the requirements of categories 2 and 3 for dust and gas zones in accordance with the European Machinery Directive 2014/34/EU. Explosion protection for systems in accordance with ATEX directive 137 (1999/9/29 EC) has also been taken into account.  The absolutely oil-free compressed-air technology, free of absorption material, made by AERZEN guarantees 100% product purity and 100% ATEX safety in pneumatic conveying of bulk material.

Aerzener Maschinenfabrik GmbH

Industrial plants all over the world are provided with gaseous media using AERZEN blowers and compressors. The innovative AERZEN machine technology represents experience of more than 150 years company history. The range of products includes rotary lobe compressors, positive displacement blowers, turbo blowers, screw compressors and gas meters. AERZEN blowers, compressors and gas meters are tested and certified according to DIN EN ISO 9001. There is a variety of product offerings from standard products to customised solutions.

In addition, the AERZEN After Sales Service offers the complete range of services - from the full maintenance contract to repairs and upgrade of existing plants.
